Chapter 5 - Maintenance 57
Use a 3/32” Allen
wrench to remove the
4 back cover screws
shown in figure 5.8.
(Figure 5.9) Spindle Cover
0
Sp in d le C o v e r
The top cover can now
be pushed to the back.
Remove the front
spindle cover as seen
in figure 5.9.
