58 VE810 Engraver Manual
(Figure 5.10) Carriage Cover
Remove the four
carriage cover screws
on each side of the
carriage cover using a
3/32“ Allen wrench as
seen in figure 5.10.
(Figure 5.11) Motor Brush Caps
Locate the motor
brush caps.
See figure 5.11
