33
ВАРШ.201219.009РЭ
2.1.1.11 VisorJet Smart Fisheye Series, Model: VJS-F603-12
2.1.1.12 The product is made in a metal case with plastic inserts.
2.1.1.13 The product contains the following connectors:
 RJ-45 port for connecting the product to an Ethernet network of the IEEE 802.3, IEEE
802.3af or IEEE 802.3at standards;
 microSD slot.
Optional:
 DC connector for connecting a 12 V or ~ 24 V power supply;
 GPIO connector;  audio jack;  RS485.
2.1.1.14 The product is also equipped with:
 built-in IR illumination;
 Reset button;
 motorized lens, Bullet, Dome, PTZ;
 360 ° rotary mechanism in PTZ version.
2.1.2 Operation
2.1.2.1 The product can operate both independently and as part of video surveillance systems
installed at the facility.
Microphone
Binding screw
Ground screw
Reference
mark
Wall mounting
Suspension
mounting
Audio output
+12V
