Vitrek V4 – Electrical Safety Tester USER MANUAL
18
5-3. Structure of Storage Steps
The storage steps of EST are total 10 groups (group 0 ~ group 9), 16 steps (step 1 ~ step 16) for each group.
Except these steps, there is another step “COM” for special test. The presentation of storage steps is Group:
Step. The first number represents group while the second represents step.
Group
0
Group
1
Group
2
Group
3
Group
4
Group
5
~
Group
9
Step 1 0:1 1:1 2:1 3:1 4:1 5:1 9:1
↓ ↓ ↓ ↓ ↓ ↓ ↓
Step 2 0:2 1:2 2:2 3:2 4:2 5:2 9:2
↓ ↓ ↓ ↓ ↓ ↓ ↓
Step 3 0:3 1:3 2:3 3:3 4:3 5:3 9:3
↓ ↓ ↓ ↓ ↓ ↓ ↓
Step 4 0:4 1:4 2:4 3:4 4:4 5:4 9:4
↓ ↓ ↓ ↓ ↓ ↓ ↓
Step 5
∣
Step 16
0:5
0:16
1:5
1:16
2:5
2:16
3:5
3:16
4:5
4:16
5:5
5:16
9:5
9:16
The special test step “COM” contains another two types of test: CAC and CDC. The function of CAC (CDC)
is as same as ACW (DCW), except user could adjust the output voltage during test.
After each step has been tested, the tested status will be shown on the screen:
Step 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6
Test P P P P P P P P P P P P P P P P
N: Empty
P: Pass
F: Fail
Step 1: CH1
Step 2: CH2
Step 3: CH3
Step 4: CH4
Step 5: CH5
Step 6: CH6
Step 7: CH7
Step 8: CH8
Step 9: CH9
Step 0: CH10
Step 1: CH11
Step 2: CH12
Step 3: CH13
Step 4: CH15
Step 5: CH15
Step 6: CH16
