Vitrek V4 – Electrical Safety Tester USER MANUAL
2
TABLE OF CONTENTS PAGE
1. PRODUCT INTRODUCTION..........................…..
1-1. Description…………………………..………...
1-2. Feature………………………………….……...
5
5
6
2. SPECIFICATIONS………………………………... 7
3. PRECAUTIONS BEFORE OPERATION…….…
3-1. Unpacking the Instrument……..……………..
3-2. Safety Notice………………..………………….
3-3. Environment…………………………….…….
10
10
10
11
4. PANEL INTRODUCTION……………………..…
4-1. Front Panel…………………………………….
4-2. Rear Panel……………………………………..
11
11
12
5. OPERATING INSTRUCTIONS…..……………...
5-1. Main LCD Display..…………………………...
5-2. Preparing the EST for Use.…………………..
5-3. Structure of Stored Test Steps.……………….
5-4. Menu Parameter Setup & Operation………..
5-5. Remote Interface Operation.…………………
14
14
15
22
23
26
6. MAINTENANCE………..………………………… 27
7. PROGRAMMING…………………………………
7-1. Introduction…………………………………...
7-2. Connecting the V4 via the GPIB interface…..
7-3. Connecting the V4 via the RS232 interface….
7-4. Input and Output Queue……………………..
7-5. Commands and Syntax………………………..
7-6. Details of Command Reference………………
7-7. Status and Error Reporting…………………..
28
28
28
29
31
31
38
53
8. TROUBLE SHOOTING & MAINTENANCE..…
8-1. Fuse Rating and Type…………………………
8-2. Cleaning.………………………………...……..
8-3. Trouble Shooting.……..…………………...…..
8-4. V4 Calibration Procedure…………………….
58
58
58
58
59
