Vitrek V4 – Electrical Safety Tester USER MANUAL
32
Combining Commands
You can use a semicolon (;) to combine commands. But continuously query command will cause message
missing. For example
:GRO:STEP: ACWS:VOLT:;CMAX?
If the command that follows the semicolon has a different header path from the root level, you must
use a colon to force a return to the root level.
:ACC:CMIN 1.00;:ACC:CMAX 2.00
If the command that follows the semicolon has the same header path, you may omit the colon and the path
and state only the new leaf node. For example:
:ACC:CMIN 1.00;:ACC:CMAX 2.00
is equal to
:ACC:CMIN 1.00;:CMAX 2.00
You can combine commands and queries into the same message. Note, for example, the following
combination:
:ACC:CMIN 1.00;CMIN?
Synopsis of Commands
The tables in this section summarize the command of the programmable power supply. These tables
divide the commands into three functional classifications:
z General Setting Commands: control and query the settings of the power supply
z Status Commands: set and query the various registers and queues that make up the status and event
structure of the programmable power supply.
z Miscellaneous Commands: control general housekeeping functions of the programmable power
supply.
Table 2: General Setting Commands
Commands Explanation
:GROup <NR1> Set the value of group
:GROu? Query the value of group
:STEP <NR1> Set the value of step
:STEP? Query the value of step
:FUNCtion:TEST:MODe <NR1> Set the value of test mode
:FUNCtion:TEST:MODe? Query the value of test mode
:FUNCtion:TEST:STATe <NR1> Set the value of test state
:FUNCtion:TEST:STATe? Query the value of test state
:MEASure<x>? Query the value of measurement
:UTILity:AC:FREQuency <NR1> Set the value of AC frequency
:UTILity:AC:FREQuency? Query the value of AC frequency
:UTILity:ARC:CURRent <NR2> Set the value of ARC current
:UTILity:ARC:CURRent? Query the value of ARC current
:UTILity:ARC:MODe <NR1> Set the ARC test mode
