There are two status registers are included to the EST defined by IEEE-488.1 and IEEE-488.2 standards.
1. Status Byte Register (SBR)
2. Standard Event Status Register (SESR)
Status Byte Register (SBR): The SBR (Table 6) summarizes the status of all other registers and queues.
Table 6: Status Byte Register (SBR)
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
OPER RQS/MSS ESB MAV QUES E/E NU NU
The bit 0 and 1 are not used, so these bits are always zero. The bit 2 (Error and Event) indicates an error code
is waiting to be read in the Error Event Queue. The bit 3 (QUES, QUEStionable) is the summary bit for the
QESR (QUEStionable Event Status Register). When the bit is high it indicates that status is enabled and
present in the QUES. The bit 4 (MAV, Message Available) indicates that output is available in the output
queue. The bit 5 (ESB, Event Status Bit) is the summary bit for the Standard Event Status Register (SESR).
When the bit is high it indicates that status is enabled and present in the SESR. The bit 6 (RQS, Request
Service) is obtained from a serial poll and shows that the EST requests service from the GPIB controller. The
bit 7 (OPER, OPERation) is the summary bit for the OESR (OPERation EVENt STATus Register).
Use the serial poll or the *STB? Query to read the contents of the SBR. The bits in the SBR are set and
cleared depending on the contents of the Standard Event Status Register (SESR), the Standard Event Status
Register (SESR), and the Output Queue.
Table 7: Standard Event Status Register (SESR)
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
PON URQ CME EXE DDE QYE NU OPC
The bit 0 (OPC, Operation Complete) shows that the operation is completed. This bit is active when all
pending operations are completed following an *OPC command. The bit 1 is always zero. The bit 2 (QYE,
Query Error) indicates a command or query protocol error. The bit 3 (DDE, Device Error) shows that a device
error occurred. The bit 4 (EXE, Execution Error) shows that an error occurred while the EST was executing a
command or query. The bit 5 (CME, Command Error) shows that an error occurred while the EST was
parsing a command or query. The bit 6 (USR, User Request) indicates the LOCAL button was pushed. The bit
7 (PON, Power On) shows that the EST was powered on.
Use the *ESR? Query to read the SESR. Read the SESR and clear the bits of the registers so that the register
can accumulate information about new events.
Enable Registers
The enable registers determine whether certain events are reported to the Status Byte Register and SRQ. The
EST has the following enable registers:
• Event Status Enable Register (ESER)
• OPERation Enable Register
• QUEStionable Enable Register
Service Request Enable Register (SRER)
When one of the bits of the enable registers is high and the corresponding bit in the status register is high, the
