Vitrek V4 – Electrical Safety Tester USER MANUAL
7
Operating Environment: Indoor use, Altitude up to 6500ft (2000m). Installation Category II. Pollution
Degree 2
Operating Temperature: 0°C to 40°C, 80% RH max.
Storage Temperature: -10°C to 70°C, 70% RH max
Dimension: 17.6”L x 13”W x 5.9”H, 446(L) x 330(W) x 149(H) mm
Weight: 30 lbs (14kg) net, 34 lbs (16 kg) ship
Accessories: NIST certification, TL-2050 Test Leads, Instruction Manual and power cord
Accuracy: Stated specifications apply for 1 year at 23 °C ± 5 °C
Calibration: Certificate of calibration, traceable to NIST provided
Compliance: CE mark certified to EN61010 and EMC directives EN50081-1 & EN50082-2
QuickTest™ Software Option QT-2: Bundled test automation software, with PC GPIB interface and cable.
It has an easy to load graphical test sequence development and operating environment. Provides time/date,
operator, test parameters, and test results for review, printout or export to database program.
Figure 2-1
AC Hi-Pot
Spec 180sec
AC Hi-Pot Spec
Continuous
DC Hi-Pot Spec
Continuous
40
35
0
2
4
6
8
10
15
20
25
30
mA
.1 .5 1kV 2 3 4 5 6 kV
