DLP Projector—User’s Manual
– 12 –
ITEM LABEL DESCRIPTION
AUDIO OUT Connect an AUDIO cable for audio loop through
AUDIO IN (BNC) Connect an AUDIO cable from the input device
RS-232C Connects RS-232 serial port cable for remote control
AUDIO IN L/R RCA
(YPbPr)
Connect the audio cables from a audio device
12V OUT
When connected to the screen through a commercially available cable, the
screen deploys automatically on start up of the projector. The screen retracts
when the projector is powered off (see notes below).
AUDIO IN L/R RCA
(Video/ S-Video)
Connect the audio cables from a audio device
VIDEO Connect the composite cable from a video device
S-VIDEO Connect the S-video cable from a video device
YPbPr Connect a component video enabled device
BNC Connect an BNC cable from a computer or a video enabled device
Warning:
As a safety precaution, disconnect all power to the projector and connecting devices before making
connections.
