DLP Projector – User’s Manual
– 11 –
Connecting Input Devices
A PC or notebook computer and video devices can be connected to the projector at the same time. Video
devices include DVD, VCD, and VHS players, as well as movie camcorders and digital still cameras.
Check the user manual of the connecting device to confirm it has the appropriate output connector.
ITEM LABEL DESCRIPTION
VGA1 IN/SCART/
YPbPr
Connect an RGB cable from a computer or a video enabled device
AUDIO IN (VGA1) Connect an audio cable from the input device
VGA2 IN/ YPbPr Connect an RGB cable from a computer or a video enabled device
DVI-D Connect the DVI cable (not supplied) from a computer
AUDIO IN (VGA2) Connect an AUDIO cable from the input device
HDMI Connect the HDMI cable from a HDMI device
USB Connect the USB cable from a computer
RJ-45 Connect a LAN cable from Ethernet
VGA OUT Connect the RGB cable to a display
To Next Page
