Vivotek FD8151V - Privacy Mask

VIVOTEK
User's Manual - 157
logo
theme_option 1~4 1 1/6 1~3: One of the default themes.
4: Custom definition.
theme_color_font string[7] #ffffff 1/6 Font color
theme_color_configfont string[7] #ffffff 1/6 Font color of configuration
area.
theme_color_titlefont string[7] #098bd6 1/6 Font color of video title.
theme_color_controlbackgroun
d
string[7] #565656 1/6 Background color of control
area.
theme_color_configbackground string[7] #323232 1/6 Background color of
configuration area.
theme_color_videobackground string[7] #565656 1/6 Background color of video area.
theme_color_case string[7] #323232 1/6 Frame color
custombutton_manualtrigger_s
how
<boolean
>
1 1/6 Show or hide manual trigger
(VI) button in homepage
0 -> Hidden
1 -> Visible
7.22 Privacy mask
Group: privacymask_c<0~(n-1)> for n channel product
NAME VALUE DEFAULT SECURITY
(get/set)
DESCRIPTION
enable <boolean> 0 4/4 Enable privacy mask.
win_i<0~4>_enable <boolean> 0 4/4 Enable privacy mask
window.
win_i<0~4>_name string[14] <blank> 4/4 Name of the privacy mask
window.
win_i<0~4>_left 0 ~ 320/352 0 4/4 Left coordinate of window
position.
win_i<0~4>_top 0 ~ 240/288 0 4/4 Top coordinate of window
position.
win_i<0~4>_width 0 ~ 320/352 0 4/4 Width of privacy mask
window.
win_i<0~4>_height 0 ~ 240/288 0 4/4 Height of privacy mask
window.
