Vivotek FD8151V User Manual

VIVOTEK
User's Manual - 7
Hardware Installation
Removing the Dome Cover
1� Unscrew the anit-tamper screws using the
included screwdriver�
2� Remove the dome cover�
3� Remove the slide cover if you want to
route cables from the side of camera
instead of a hole on the ceiling or wall�
0002D10766AD
FD8151V-F2
1� Record the MAC address before
installing the camera�
IMPORTANT:
1� It is recommended to use an Ethernet
cable that comes without the strain relief
boot� You can remove the boot if your cable
comes with one�
Strain relief boot
NOTE:
2. You can check the model name sufx
for the type of lens mounted on your
camera� The applicable lens can be:
F2: 2�4mm; F4: 4mm; F8: 8mm� The
shorter the focal length, the wider the
view�
2� As shown below, you may also route cable
from the side�
