VIVOTEK
54 - User's Manual
Media > Video
► All the items in the “Region of Interest” should not be larger than the “Output Frame Size“
(current maximum resolution)�
■ The parameters of the multiple streams:
When completed with the settings in the Viewing Window, click Save to enable the settings and
click Close
to exit the window� The selected Output Frame Size will immediately be applied to
the Frame size
of each video stream� Then you can go back to the home page to test the e-PTZ
function� For more information about the e-PTZ function, please refer to page 90�
Region of Interest
(Viewing Region)
Output Frame Size
(Size of the Live View Window)
X2.1
Region of Interest Output frame size
Stream 1 1280 X 1024 ~ 176 x 144 (Selectable) 1280 X 1024 ~ 176 x 144 (Selectable)
Stream 2 xed xed
NOTE:
