Vivotek FD8151V User Manual

VIVOTEK
170 - User's Manual
weekday 0~127 127 6/6 Indicate which weekday is scheduled.
One bit represents one weekday.
bit0 (LSB) = Saturday
bit1 = Friday
bit2 = Thursday
bit3 = Wednesday
bit4 = Tuesday
bit5 = Monday
bit6 = Sunday
For example, to detect events on Friday and
Sunday, set weekday as 66.
begintime hh:mm 00:00 6/6 Start time of the weekly schedule.
endtime hh:mm 24:00 6/6 End time of the weekly schedule.
(00:00~24:00 indicates schedule always on)
prefix string[16] <blank> 6/6 Indicate the prefix of the filename.
cyclesize 100~ 100 6/6 The maximum size for cycle recording in
Kbytes when choosing to limit recording size.
reserveamount 0~ 100 6/6 The reserved amount in Mbytes when
choosing cyclic recording mechanism.
dest cf,
0~4
cf 6/6 The destination to store the recorded data.
“cf” means local storage (CF or SD card).
“0” means the index of the network storage.
cffolder string[128] <blank> 6/6 Folder name.
maxsize 100~900 100 6/6 Unit: Mega bytes.
When this condition is reached, recording file
is truncated.
maxduration 60~1800 60 6/6 Uuit: Minute
When this condition is reached, recording file
is truncated.
trigger schedule,
networkfail
schedule 6/6 The event trigger type
schedule: The event is triggered by schedule
networkfail: The event is triggered by the
failure of network connection.
adaptive_enable 0,1 0 6/6 Indicate whether the adaptive recording is
enabled
adaptive_preevent 0~9 5 6/6 Indicate when is the adaptive recording started
before the event trigger point (seconds)
adaptive_posteven
t
0~10 5 6/6 Indicate when is the adaptive recording
stopped after the event trigger point (seconds)
