VIVOTEK
User's Manual - 91
Home page in E-PTZ Mode
■ The e-Preset Positions will also be displayed on the home page� Select one from the drop-down
list, and
the camera’s view area will move to the selected e-preset position�
■ If you have congured different e-preset positions for different streams, you can select one of the
video streams to display its separate e-
preset positions�
Global View
In addition to using the e-PTZ control panel, you can also use the mouse to drag or resize the
floating frame to pan/tilt/zoom the viewing region. The live view window will also move to the
viewing region accordingly�
Moving Instantly
If you check this item, the live view window will switch to the new viewing region instantly after you
move the oating frame. When not selected, the travelling process from one spot to another will be
shown, although it is not easily observed unless you have a small eld of interest.
Click on Image
The e-PTZ function also supports “Click on Image“� When you click on any point of the Global View
Window or on the Live View Window, the viewing region will also move to that point�
Note that the”Click on Image” function only applies when you have congured a smaller “Region of
Interest” out of the maximum output frame, e�g�, a 800x600 region from the camera’s 1280x1024
maximum frame size. This enables you to travel to other unrevealed areas within the maximum
frame size.
