Ensure wiring and in-cab installed electronics keep away
from, and do not interfere with, the operation of the park
brake mechanism, brake & accelerator pedals, and steering
column.
5.2.3 Hood Switch
Figure 5.3
□ If the vehicle comes equipped with a hood switch, splice and
seal the OEM blue w/pink hood switch wire with VMAC’s grey
hood-switch wire, See Figure 5.3. Ensure VMAC’s black hood-
switch connector wire is left unexposed, as it is at 12V. Skip to
section 5.2.4
□ If the vehicle doesn’t come equipped with hood switch, using the
provided screw, install hood switch in a pre-existing hole in the
engine bay, near the driver’s headlight. See Figure 5.4
