8. Mark the position of the power steering pump pulley in relation to the pump shaft so that
you can install it back into the original position.
9. Remove the power steering pump pulley using a manufacturer approved puller.
10. Remove the three (3) OEM hex head cap screws retaining the power steering pump to the
bracket and the 10mm hex head cap screw from the cylinder block support bracket.
11. Remove the stud from the cylinder head that is used to locate and retain the OEM air
conditioning and power steering bracket.
12. Remove the OEM fasteners retaining the air conditioning compressor/power steering pump
mounting bracket to the cylinder head and discard the bracket. Figure 2 shows the engine
block with the OEM bracket removed and the power steering pump pulley removed.
Figure 2
13. Clean all dirt and debris from the inside of the OEM crankshaft pulley.
14. Remove the OEM fasteners holding the OEM pulley in place on the crankshaft.
15. Install the VR7000 pulley in place over the OEM crankshaft pulley.
16. Install and tighten the three (3) supplied 3/8 x 3-1/2 inch NF hex head cap screws and one
(1) 1/2 x 3/8 inch NF hex head cap screw in the center of the pulley.
12
DOCUMENT 19296
Three C
linder Head Locations
Two Cylinder Block Locations
