Installation Notes
1. It is important that you complete all the installation steps before operating the system.
Refer to the Owner’s Manual before operating the system for the first time.
2. Follow all safety precautions for underhood mechanical work.
3. Use Loctite 242 or equivalent on all engine-mounted fasteners.
4. All hoses, tubes and wires which are re-routed or shifted during installation must be
secured so that they do not contact excessively hot areas or sharp edges. Where
possible, follow the routing instructions in this manual.
5. These installation instructions are intended as a general guide. In some instances, due
to variations in vehicle manufacture or if prior modifications have been made to the
vehicle, it may be necessary to carry out grinding, bending or rearranging operations
for correct fit. These operations must follow sound, standard shop practices.
6. Left and right definitions in this manual are determined when sitting in the driver’s
seat, facing forward.
7. All fasteners must be of the correct size and torqued according to the specifications
shown below. Torque specifications are in foot pounds (ft-lb).
8. The possibility exists that the primary installer may be color-blind. Always ensure
that another person confirms the color codes on the wires.
6
T
pe Grade 8 plated Class 10.9 unplated
Size In Cast or
Steel
In
Aluminum
In Cast or
Steel
In
Aluminum
3/8 48 45
7/16 77 70
1/2 117 95
M8 25 20
M10 45 40
M12 80 70
M14 145 130
DOCUMENT 19295a
