VOGELS VGI - PIN-OUT ECU VGI 4 Cyl. MP 48 OBD

Vogels Autogas Systems VGI Hardware Manual System Description and Installation
VGI Technical Manual 2014-01-14.pdf Pagina 29 van 44
1.12.3.1 PIN-OUT ECU VGI 4 Cyl. AEB MP 48 OBD
pin DESCRIPTION pin DESCRIPTION
1A Injector B 4 cut-out (INJ side) 2A Injector B 4 cut-out (ECU side)
1B Lambda probe emulation 2B Lambda probe input signal
1C Gas temperature signals 2C Temperature sensor negative
1D Fuel level 2D Fuel level
1E Pressure sensor power supply 2E Gas pressure input signal
1F P/G/P command switch 2F Switch positive (5v)
1G RPM signals for switching fuel 2G Switch negative
1H Diagnosis power supply 2H Receipt of diagnosis data
1J Transmission of diagnosis data 2J Diagnostics negative
1K Power supply Gas injector N° 1 2K Power supply Gas injector N° 2
1L Tank solenoid positive 2L Tank solenoid negative
1M Regulator solenoid positive 2M Regulator solenoid negative
3A Injector B 3 cut-out (ECU side) 4A Injector B 3 cut-out (INJ side)
3B ENGINE RPM signal 4B Injector B 2 cut-out (INJ side)
3C Temperature signal 4C Injector B 2 cut-out (ECU side)
3D Temperature negative 4D Injector B 1 cut-out (ECU side)
3E MAP signal input 4E Injector B 1 cut-out (INJ side)
3F Battery negative 4F INJECTOR G 4 signal
3G Ignition (15) 4G INJECTOR G 1 signal
3H - 4H INJECTOR G 3 signal
3J - 4J INJECTOR G 2 signal
3K Gas injector 3 power supply 4K Power supply Gas injector N° 4
3L Battery negative 4L Battery negative
3M Battery positive 4M Battery positive
