Digidrive V2
User Manual
14
 High Pass, 20Hz (off) to 20kHz, in 1, 10, 50 and 100Hz
steps. Depressing control wheel button, users can
enable/disable it and change the Filter Type.
 P
EQ 1-10, 20Hz to 20kHz, in 1, 10, 50 and 100Hz steps.
Gain from -12dB to +12dB in 0.25dB steps. Q from 0.20
to 25 in 0.10 steps. Change from Freq/Gain/Q by
depressing the control wheel.
 L
imiter, -48.00dBu to +12.00dBu on Outputs,
Depressing control wheel button, users can change the
Release, from 10 to 100
 L
ink, select whether inputs A/B are linked as a stereo
pair.
In A HighPass
Type: BUT 24dB
In A PEQ XX
Q: 1.00
In A Limiter
Thr.: 0.75dBu
In AB Link:
On
-48.00dBu to +24.00dBu on inputs, in 0.25dBu steps.
