Digidrive V2
User Manual
24
The delay control ranges from 0ms to 2000ms.
The limiter on the output is there to stop and unwanted
clipping from high peaks in the audio
The m
ute button is linked to the mute button on the main
tab, and will cut the channel. The i
nvert button is linked
to the p
hase invert on the X-over tab and will invert the
polarity of the signal. When the button is blue, phase is
inverted.
The top left-hand part of the output window is the I
nput
M
ixer. This part of the output tab allows the user to route
any input (A-D) to any output, from -48.00dB (mute) to
+12.00dB, with the gain fader in the mixing matrix.
N
OTE: The Input/Output EQ windows can be saved as a .png picture
file by clicking the c
amera icon in the top-left hand side of the
graphical EQ window in the I
nput/Output tabs. There is also a
m
agnifying glass icon, which allows users to set more precise
values for the EQ, and a f
ull screen icon, which, when pressed once
fits the EQ window to the Live Link window, and when pressed again
sets the EQ window to full screen view. To exit full screen, press the
X
icon. The T icon shows the information for the EQ previously
changed.
N
OTE: When moving a certain band in the graphical EQ window,
holding C
TRL and clicking will limit movement to horizontal (for Freq
and Q). Holding S
hift and clicking will limit movement to vertical (for
Gain).
7
.7………………………………………………....................Upgrade
To upgrade the firmware on the Digidrive V2, in the top menu bar go
to H
ardware -> Firmware Update and follow the instructions.
N
OTE: Updating the firmware on your device will erase all data/
presets on it. It is highly recommended to back-up all presets before
performing an update.
