38
F 2 (BASE ): Manual decrease of the time range
F 3 (BASE ): Shifting the displayed signal to the left
F 4 (BASE ): Shifting the displayed signal to the right
Trigger: By pressing the TRIG button, you activate the mode for setting the trigger
function. The trigger enables the signal display at a desired spot. The set trigger
threshold is displayed on the right side of the display with a small line. In this mode,
the function buttons F1 - F4 have the following function:
F 1 (TRIG ): Increasing the trigger threshold
F 2 (TRIG ): Reducing the trigger threshold
F 3 (AUTO): Switching between the trigger modes AUTO (automatic triggering),
NORM (triggering acc. to set values) or SHOT (single shot triggering).
F 4 SLOP): Switching the triggering with increasing ( ) or decreasing slope
().
DMM operation
Never exceed the maximum admissible input values in excess vol-
tage category II or III. Do not touch any contacts or contact parts if
these carry higher voltages than 25 V ACrms or 35 V DC! Risk of
fatal injury! Before measuring, check the connected measuring
lines for damage such as, for example, cuts, cracks or squeezing.
Replace defective measuring lines immediately by new ones,
defective measuring lines may not be used any longer! Risk of fatal
injury!
Switch on the DMM via the rotary switch (3) and select the first measuring function
(V ).
Select DMM mode with the MODE button.
The display shows the measuring value, the measuring unit, the
measuring range as well as the assignment of the function but-
tons.
