51
With 10A measuring range max. measuring duration 10 seconds, break 15 minutes
Resistance range, overload protection 1000V DC/AC
Range Accuracy Resolution
400 Ω ±(1.2% + 5 dgt) 0.1 Ω
4 kΩ
±(1% + 5 dgt)
0,001kΩ
40 kΩ 0.01 kΩ
400 kΩ 0.1 kΩ
4 MΩ ±(1.2% + 5 dgt) 0.001 MΩ
40 MΩ ±(1.5% + 5 dgt) 0.01 MΩ
Frequency range, overload protection 1,000V DC/AC
Range Accuracy Max. resolution
10Hz – 10 MHz ±(0.1% + 3 dgt) 0.001 Hz
Sensitivity: < 1 MHz 300 mVrms, > 1 MHz 600 mVrms
Capacity range, overload protection 1000V DC/AC
Range Accuracy Resolution
40 nF ±(3% + 10 dgt) 10 pF
400 nF
±(3% + 8 dgt)
100 pF
4 µF 1 nF
40 µF 10 nF
100 µF ±(4% + 8 dgt) 100 nF
Acoustic continuity tester ....ca. 100 Ω, overload protection 250VDC/AC
Diode test ............................0.5 to 0.8 V, resolution 1mV,
Overload protection 250VDC/AC
Measuring tolerances SCOPE operation
Bandwidth 8 MHz
Sampling rate realtime 40 MS/s
Sampling rate equivalent 200 MS/s
Vertical resolution 8 bit
Time scale 100ns to 5s/DIV (steps of 1, 2 or 5)
Accuracy time scale ± 0,01%
Horizontal deflection 20mV to 200 V/DIV (steps of 1, 2 or 5)
Accuracy horizontal deflection ± 5%
Input impedance 1 MΩ
In no event exceed the max. permitted input values. Do not contact
circuits or parts of circuits if the voltages applied could be higher
than 25 V ACrms or 35 V DC. Risk of fatal injury!
