Group
28
Ignition
systems
Fault
tracing
, Rex-I
=n-
"
<::t.EL!..j-
-O
R
146 729
->
"
11.. -
OA
146 729
N29
Check ignition
coil/power
stage
ground
connec-
tions
Measure resistance
between
terminal
B in 3-
pole
con-
nector and
ground.
Resistance
must
not
exceed
0.1
ohm.
If resistance
is
too
high,
clean
ground
connection
and/
or
replace
ground
lead
as
required
.
Measure resistance
between
terminal
A in 2-pole con-
nector and
ground
. Clean
ground
connection
and/or
re-
place
ground
lead
as
required
if
resistance exceeds
0.1
o
hm
.
224
3
~
, '
dE.,.
,,-,,-_
,,
......
J2'-1-"
N30
Check
signal
lead
between
ignition
coil/power
stage
and
control
unit
Connect buzzer
between
terminal
B
in
2-pole connec-
tor
and
terminal
16
in
control
unit
connector.
Buzzer
should
sound
if
lead is
intact
.
N31
Persistent failure
of
engine
to
start
despite
absence
of
faults
or
correction
of
fault(s}
which
have been located
indicates internal
fault
in
control
unit
or
power
stage.
Verify
by
installing
new
control
unit
or
new
power
stage.
Reinstall
ignition
coil. Reassemble
control
unit
connec-
tor
and reconnect
to
unit.
Reconnect
ignition
coillpower
stage
connectors
.
Check
that
no
new
fault
codes are displayed.
