Gr oup 28 Ignition sys tems
Fault tracing, Rex-'
'31 no
~
"
, ,
, ,
, ,
, ,
, ,
, ,
, ,
,
Inspection end checking
N71
Undo control un it connector
Caut ion! The igni ti on must be sw itc hed off whenever
the connec tor is disconnected or reconnect-
ed.
Remove panel under leh-hand side of instrument
panel.
Re lease c onnector catch and separate connector from
control un it.
N1 2
Remove protective cover from connector
Caution! Never insert ins t rument probes into front of
co nnector termina ls. This may cause dam-
age which will aggravate any faults present.
Always connect probes to terminals through holes in
connecto r side. tak in g care to avoid unn ecessa ry force.
Terminal numbers are marked on side of connector.
N 13
ChKk that all terminal s ockets are at same
hei ght in connector
Poor contact may result one terminal socket is lowe r
than the others.
N14
s
J=l.
12V I
~
,
V
.
' .... to1
..".,
ChK k bushar 30 supply
Measure volt age between control unit connector termi-
nal 5 ( brown ) and ground . Readi ng should be approx .
12 V.
If no readi ng is indicated , check lead between control
un it sleeve and busbar 30 supply at fuseholder .
