Layer no. 2–25
Rotate every new layer to avoid thicker areas. Each
layer
must be extended (C) minimum 50 mm (2”) from
the previous layer.
Outside hull lamination
Grind a wedge from outside in hull. Laminate the tran-
sition and grind to a smooth area.
C
P0012013
P0011594
1
2
3
