TP 39212202 C30/S40 (04-)/V50/C70 (06-) 2012 16

Fuses

Main fuse box battery

15/34 Main fuse box battery

No. Fuse function via A

11M/1 6/26 Alternator

15/31 Distribution box in engine compartment

2/242

-

125

11M/2 7/240 Battery monitoring sensor (BMS) - 15
