Volvo V50 2012 - Page 43

TP 39212202 C30/S40 (04-)/V50/C70 (06-) 2012 43
Control modules
Data communication, Low speed CAN 2:2
A
B
9
10
CAN
5/1
DIM
BU-WH
GY-VT
A:9
CAN
A:10
ICM
3/281
A:8
A:7
GY-RD
BU-WH
C°/F°
CAN
11
9
8
10
CCM
3/112
GY-BK
BU-YE
G029729
