Multi-Sensor Cameras VRmMFC
Multi-sensor cameras consist of a base unit and up to four external sensor boards con-
nected to the base unit by flex-foil cables. They are available as board-level cameras
(OEM versions) and board-level cameras with optics (COB versions).
The base unit consists of a sensor connection board, an FPGA board, and an interface
board.
Front View Side View Back View
Fig. 4: Base unit of USB multi-sensor camera with standard interface board
1 Sensor connection board (external sensor boards are connected via flex-foil
cables)
2 FPGA board
3 Interface board
