8
TEBS E
Installation notes
for vehicle installation and retrofitting
160
Installing the LIN ultrasonic sensors
As of version TEBS E2 and
ELEX0
As of version TEBS E2.5
and ELEX1
Upper (additional level) External 446 122 402 0 /
446 122 404 0 – 15° vertical
External 446 122 402 0 /
446 122 404 0 – 15° vertical
Lower (main level) External 446 122 402 0 /
446 122 404 0 – 15° vertical
External 446 122 402 0 /
446 122 404 0 – 15° vertical
Internal 446 122 401 0 – 0°
vertical
Internal 446 122 401 0 – 0°
horizontal
Installation height
0.4…1.2 m
(see figure
‘TailGUARD
Roof
installation
dimensions’)
Installation height
0.8…1.2 m
(see figure ‘TailGUARD
Installation dimensions’)
More installation alternatives are possible based on the TEBS E Diag-
nostic Software.
