16 Technical data
40 100_0202_td_0027.fm
16.3 Rechargeable battery
16.4 Battery charger
Designation BP1000
Item number 5100025709
Rated voltage V 51
Kind of current (output) DC
Length mm 220
Width mm 290
Height mm 197
Weight kg 9.4
Battery product identification 14INR19/65/-8
Battery type Lithium ion
Energy content Wh 1,008
Capacity Ah 20
Max. discharge current A 160
Max. charging current A 32
Protection rating IP2X
Storage temperature range °C -30 – +50
Operating temperature range
when charging
°C 0 – +45
Designation C48/4
Item number 5100006221
Rated voltage V 230 (90 – 265)
Kind of current (input) AC 1~
Rated current A <3
Rated frequency Hz 50 – 60
Kind of current (output) DC +/-
Output current A 4 +/-0.5
Max. output voltage V 57.6
Length mm 190
Width mm 145
Height mm 65
Weight kg 2.0
Power cable mm 1500
Power cable mm 1800
Class rating II.
Protection rating IP54
Storage temperature range °C -30 - +50
Operating temperature range °C 0 - +45
