Technical Data
APS 15.3
61
[en] | 02/2022 | 5100060593 | APS | Operator’s Manual
Type APS1135we APS1135e
Material number machine 5100059661 5100059664
Operating weight [kg] 63 58
Operating temperature range [°C] 0 - +40 0 - +40
Storage temperature range [°C] -30 - +50 -30 - +50
Sound pressure level at operator station LpA [dB(A)] 85 85
Sound power level LWA, measured [dB(A* 98 98
Sound power level LWA guaranteed [dB(A)] 105 105
Vibration total value ahv [m/s2] 4,9 4,9
Measurement uncertainty of the total vibration value
ahv [m/s2]
0,5 0,5
*Depends on the soil conditions.
** Corresponds to the installed net power according to Directive 2000/14/EC.
Type APS1340we APS1340e
Material number machine 5100059663 5100060128
Rechargeable battery material number 5100025709
5100048620
5100060982
5100025709
5100048620
5100060982
Centrifugal force [kN] 13 13
Vibrations [Hz] 98 98
Vibrations [1/min] 5880 5880
Area output* [m2/h] 624 624
Flow [m/min] 26 26
Gradeability [%] 46,6 46,6
Nominal power** [kW] 1,2 1,2
Rated current [A] 21,5 21,5
Rated voltage [V] 51 51
Protection type IP23D IP23D
Type of current (output) DC DC
Length (drawbar in working position) [mm] 930 930
Width [mm] 400 400
Height [mm] 663 663
Underclearance [mm] 663 663
Operating weight [kg] 75 68
Operating temperature range [°C] 0 - +40 0 - +40
Storage temperature range [°C] -30 - +50 -30 - +50
Sound pressure level at operator station LpA [dB(A)] 91 91
Sound power level LWA, measured [dB(A* 100 100
Sound power level LWA guaranteed [dB(A)] 105 105
Vibration total value ahv [m/s2] 3,1 3,1
Measurement uncertainty of the total vibration value
ahv [m/s2]
0,5 0,5
15
