Technical Data
Rechargeable battery 15.4
63
[en] | 02/2022 | 5100060593 | APS | Operator’s Manual
Type APS2050we APS2050e
Material number machine 5100061222 5100061221
Vibrations [1/min] 5880 5880
Area output* [m2/h] 750 750
Flow [m/min] 25 25
Gradeability [%] 46,6 46,6
Nominal power** [kW] 1,2 1,2
Rated current [A] 21,5 21,5
Rated voltage [V] 51 51
Protection type IP23D IP23D
Type of current (output) DC DC
Length (drawbar in working position) [mm] 970 970
Width [mm] 500 500
Height [mm] 663 663
Underclearance [mm] 663 663
Operating weight [kg] 92,1 86,7
Operating temperature range [°C] 0 - +40 0 - +40
Storage temperature range [°C] -30 - +50 -30 - +50
Sound pressure level at operator station LpA [dB(A)] 89 89
Sound power level LWA, measured [dB(A* 104 104
Sound power level LWA guaranteed [dB(A)] 105 105
Vibration total value ahv [m/s2] < 2,5 < 2,5
Measurement uncertainty of the total vibration value
ahv [m/s2]
0,5 0,5
*Depends on the soil conditions.
** Corresponds to the installed net power according to Directive 2000/14/EC.
15.4 Rechargeable battery
Information
Compatible chargers!
Only use the following chargers:
► C48/4
► C48/7
► C48/13
► C48/13 Systainer
Type BP500
Rechargeable battery material number 5100060982
Rated voltage [V] 51
Type of current (output) DC
Length [mm] 296
Width [mm] 396
15
