Technical Data
Battery charger 15.5
65
[en] | 02/2022 | 5100060593 | APS | Operator’s Manual
Type BP1400
Rechargeable battery material number 5100048620
Length [mm] 296
Width [mm] 396
Height [mm] 322
Weight [kg] 9,6
Labeling 14INR19/66-8
Rechargeable battery type Lithium-ions
Energy content [Wh] 1425
Capacity [Ah] 28
Protection type IP2X
Storage temperature range [°C] -30 - +50
Operating temperature range [°C] -10 - +50
Operating temperature range charging [°C] 0 - +45
Rechargeable battery runtime [min] APS1030 90
Rechargeable battery runtime [min] APS1135 90
Rechargeable battery runtime [min] APS1340 90
Rechargeable battery runtime [min] APS1550 90
Rechargeable battery runtime [min] APS2050 90
15.5 Battery charger
Information
Compatible rechargeable batteries!
Only use the following rechargeable batteries:
► BP500
► BP1000 with production date 08/2019 or later (see type label)
► BP1400
► Other incompatible rechargeable batteries switch off automatically
after 30 seconds and do not release any voltage at the plug recept-
acle.
Information
Technical data of other compatible chargers can be found in the respect-
ive operating instructions.
Type C48/4
Material number machine 5100006221
Rated voltage [V] 230 (90 – 265)
Type of current (input) AC
Phases [~] 1
Rated current [A] <3
Rated frequency [Hz] 50 – 60
15
