Wacker Neuson BS 50-4 Repair Manual

Technical Data Rammer Repair
138 wc_td000112gb.fm
10.7 BS 60/70-2
Item Number:
BS 60-2
0009388
0009417
0009421
0620612
BS 60-2
0009391
0009418
BS 70-2
0009397
0009399
0009424
0009425
0009427
Rammer
Engine Model
type
WM80
Engine Speed - full
rpm
4400 ± 100 4600 ± 100
Engine Speed - idle
rpm
1800 ± 100
Clutch Engagement
rpm
2500 ± 100
Spark Plug
type
Champion RL95YC
Electrode Gap
mm (in)
0.5 (0.020)
Cylinder Head
Compression (cold)
bar/cm
3
(psi)
8.0–9.7 (120–140)
Air Cleaner
type
Three stage with cyclonic precleaner
Engine Lubrication
oil grade
With standard two-cycle oil use 50:1 ratio.
With Wacker Neuson two-cycle or other oil
meeting the NMMA TC-W3 specification, a ratio
from 50:1 to 100:1 can be used.
Fuel Tank Capacity
l (qts.)
3.0 (3.2)
Fuel Consumption
l(qt.)/hr
1.2 (1.3) 1.3 (1.4)
Running Time
hour
2.5 2.3
Ramming System
Lubrication
oil grade
SAE 10W30
Ramming System
Capacity
ml (oz.)
890 (30)

Wacker Neuson BS 50-4 Specifications

General

Engine Manufacturer	Honda
Stroke Height	65 mm
Fuel Type	Gasoline
Centrifugal Force	15 kN
Sound Pressure Level	92 dB(A)
Sound Power Level	105 dB(A)
Height	965 mm
Ramming Shoe Size	280 mm
Tank Capacity	3.1 l
Fuel Tank Capacity	3.1 l
Engine Type	4-cycle, single-cylinder, air-cooled
Percussion Rate	680 blows/min
