BA ET18, 20, 24 en* 1.5 * et18_20_24b510.fm 5-43
Operation 5
Grab operation on the left:
1. Fit lever A onto the ball-type cock.
2. Set the ball-type cock to position B.
➥ The 90° notch indicates that grab operation is set.
3. Remove the lever after the changeover.
Fig. 195Grab operation on the left
A
B
9
0
°
