BA ET18, 20, 24 en* 1.5 * et18_20_24i400.fm 4-27
Putting into operation 4
Power outlet
A 12 V outlet is located at the front left of the machine chassis.
Swiveling console limit stop (option)
Limits the limit stop on the left of the swiveling console for attachments
with a max. width of 800 mm (31 in) and prevents the attachment from
damaging the cabin.
The limit stop can only be used for attachments with a max. width of 800
mm (31 in).
4.2 Overview of control elements
This chapter describes the controls, and contains information on the
function and handling of the indicator lights and controls in the cabin.
The pages stated in the table refer to the description of the controls.
Fig. 102Position of outlet
Fig. 103Swiveling console limit
