5-12 BA ET18, 20, 24 en* 1.5 * et18_20_24b500.fm
5 Operation
5.8 Heating, ventilation and air conditioning system
Ventilation/heating (option)
The switch is located on the switch panel on the right.
Adjust the nozzles so that the required temperature can be reached.
Air the cabin from time to time.
If the windows are fogged or iced up, adjust the nozzles to the front and
open them completely.
Temperature setting
The temperature controller is located at the right behind the seat.
Cooling
Turn temperature controller 14 toward B.
Heating
Turn temperature controller 14 toward A.
Fig. 133Ventilation/heating
41
Position Function
1st position Press switch 41 down one step Low fan speed
2nd position Press switch 41 down two steps High fan speed
OFF Press switch 41 all the way up Fan is switched off
Fig. 135Temperature setting
A
B
14
