BA ET18, 20, 24 en* 1.5 * et18_20_24i400.fm 4-29
Putting into operation 4
Designation See page
1 Accelerator pedals/drive levers
5-16
2 Boom swivel/auxiliary hydraulics pedal (AUX I)
5-32, 5-30
3 Foot-operated push button for hydraulic quickhitch (option)
5-38
4 Control lever base
4-17
5Horn
5-10
6 Control levers
5-13
7 Travel speed changeover
5-1
8 Stabilizer blade/travel gear extension/retraction (option)
5-21, 5-23
9 Display element
4-32
10 Oil flow AUX I rotary switch (proportional controls)
5-26
11 Starter
4-39
12 Switch panel on the right (cabin)
4-30
13 12 V power outlet (cabin)
--
14 Temperature controller (cabin)
5-12
15 Radio (option)
--
16 Switch panel (canopy)
4-30
17 Operator seat
4-11
18 Throttle
5-1
19 Oil flow AUX II rotary switch (proportional controls)
5-26
20 Changeover for stabilizer blade/travel gear extension/retraction
5-21, 5-23
21 Switch panel on control lever base on the left
4-30
22 Boom swivel/auxiliary hydraulics pedal changeover (AUX I)
--
23 Powertilt (AUX II) or 3rd control circuit (AUX II) operation (option)
5-36, 5-35
24 Auxiliary hydraulics (AUX I) operation (option) (proportional controls)
5-31
25 Boom swivel pedal (proportional controls)
5-32
