5-32 BA ET18, 20, 24 en* 1.5 * et18_20_24b510.fm
5 Operation
Swiveling the boom
Press and hold button A on the control lever base on the left.
Swiveling the boom to the right:
Press pedal 2 forward.
Swiveling the boom to the left:
Press pedal 2 backward.
Swiveling the boom (proportionally controlled)
Swiveling the boom to the right:
Press pedal 2 forward.
Swiveling the boom to the left:
Press pedal 2 backward.
Fig. 170Changeover of boom swivel
A
Fig. 171Boom swivel/auxiliary hydraulics pedal
2
Fig. 172Boom swivel/auxiliary hydraulics pedal
2
