Technical data 9
9 Technical data
9.1 Models and trade names
9.2 Engine
Machine model/machine designation Trade name
E12-02 ET18
E12-03 ET20
E12-04 ET24
Engine ET18 ET20 ET24
Product Yanmar diesel engine
Type 3TNV76-SNSE12
Design Water-cooled 4 stroke diesel engine
Number of cylinders 3
Displacement 1116 cm
3
(68.1 in
3
)
Nominal bore and
stroke
76 x 82 mm (2.9 x 3.2 in)
Power 13.4 kW/2200 rpm (18 hp/2200 rpm)
Max. torque 65.6 Nm/1600 rpm (48.4 ft.lbs/1600 rpm)
Max. engine speed
without load
2375 +/− 50 rpm
Idling speed 1300 +/− 25 rpm
fuel injection system Indirect injection
Starting aid Glow plug (preheating time 4 seconds)
Fuel tank 24 litres (6.3 gal)
Exhaust values
according to
EPA – Tier IV final (up to 2012)
