5-26 BA ET18, 20, 24 en* 1.5 * et18_20_24b510.fm
5 Operation
Proportional controls (option)
The proportional controls make it possible to adapt the speed with which
the attachments move. Moving the control lever slowly causes the
attachment to move slowly.
This control mode offers proportional operation of the auxiliary hydraulics
depending on the position of slide switch A on the control lever.
If precision work (for example with an offset bucket) does not require the
full oil flow of the auxiliary hydraulics (AUX I and AUX II), turn the rotary
switch to the left (MIN).
If the full oil flow is required, turn the rotary switch to the right (MAX).
A
Fig. 158Control lever for proportional controls
Fig. 159Rotary switch on control lever base on the
left
Fig. 160Rotary switch on control lever base on the
right
