BA ET18, 20, 24 en* 1.5 * et18_20_24b510.fm 5-25
Operation 5
8. Set the travel gear to the desired position.
9. Raise the control lever base.
10.Bring lever A in position 1 .
Only perform work with an extended telescopic travel gear. Lower the
stabilizer blade and turn out the extensions.
Fig. 156Extension and retraction
B
Telescopic travel gear Position
Extend Push lever B forwards.
Retract Pull lever B backward.
