6 Transport
Crane-lifting
Accident hazard due to incorrect loading!
Incorrect loading can cause accidents and serious injury or death.
► Do not allow anyone to stay in the danger zone.
► Observe the loading weight. Add the weight of subsequently installed
accessories to the weight of the vehicle.
► The machine may only be raised with suitable lifting gear.
Possible damage to the machine due to incorrect loading.
► Observe the loading weight. Add the weight of subsequently installed
accessories to the weight of the vehicle.
► The machine may only be raised with suitable lifting gear.
1. Fit an empty standard bucket and lock it safely.
2. Remove all dirt from the machine.
3. Park the vehicle on firm, level, and horizontal ground.
4. Tilt in the standard bucket and lower it to transport position.
5. Fully raise the boom.
6. Pull the stick toward the machine.
7. Raise the stabilizer blade.
8. Position the boom straight ahead at the center of the machine.
9. Stop the engine.
10.Operate the control lever repeatedly to release the pressure in the
hydraulic system.
11.Raise the control lever base.
12.Remove the starting key and carry it with you.
13.Remove all loose objects from inside the machine.
14.Leave the cabin, close and lock all doors, windows and covers.
15.Install suitable slings at the points provided for lifting the machine.
16.Slowly raise the machine until there is no more contact with the
ground.
17.Wait until the machine does not swing any more.
18.If the balance, and the condition and position of the slings is correct,
slowly raise the machine to the required height and load it.
