Wacker Neuson ET12 02

BA ET18, 20, 24 en* 1.5 * et18_20_24w700.fm 7-19
Maintenance 7
12.Canopy: Remove screws E on either side.
13.Cabin (option): Remove screws E on either side.
14.Raise the cabin as follows:
- Raise the control lever base.
- Remove the starting key and carry it with you.
- Close the doors, windows and all covers.
- Remove all loose objects from inside the machine.
- Leave the cabin.
- Close and lock all covers.
15.Set down the cabin safely and ensure that it cannot tip over.
16.Install the cabin in the reverse order.
17.Tighten screws D and E to 110 Nm (81 ft.lbs). The washers and
securing elements can be used again.
Information
Cover F can be removed for better access.
Fig. 248Screws (canopy)
E
Fig. 249Screws (cabin)
E
F
