9-6 BA ET18, 20, 24 en* 1.5 * et18_20_24t900.fm
9 Technical data
Bulbs
Powertilt (option)
ET 18 ET 20 ET 24
Working lights/roof lights Halogen lamp 12 V 55 W H3
Interior light Festoon lamp 10x38 12 V/5 W
Rotating beacon Halogen lamp 12 V-55 W H1
ET 18 ET 20 ET 24
Model size 4.5
Piston stroke 240 cm³ (14.6 in³)
Required oil flow 2 – 4 l/min (0.5 – 1 gal/min)
Connections 1/8 in
Swiveling range 180°
Weight 35 kg (77.2 lbs)
Drive torque – at 210 bar
(3045 psi)
930 Nm (685 ft.lbs.)
Holding torque – at 225
bar (3263 psi)
2470 Nm (1,820 ft.lbs.)
Minimum hose/pipe size
Connecting hose size
6 mm (0.23 in)
6 mm (0.23 in)
