9 Technical data
ET20
Telescopic travel
gear
Telescopic travel
gear + VDS
A Height 2295 mm (7'-6'') 2385 mm (7'-10'')
B1 Upper carriage width 990 mm (39 in)
B2 Width with retracted travel gear 990 mm (39 in)
B2 Width with extended travel gear 1300mm (51 in)
C Transport length 4050 mm (13'-4'') 4030 mm (12'-3'')
D1 Max. digging depth (short stick) 2490 mm (98 in) 2400 mm (94 in)
D2 Max. digging depth (long stick) 2690 mm (8'-10'') 2600 mm (8'-6'')
E1 Max. vertical digging depth (short stick) 1670 mm (66 in) 1570 mm (62 in)
E2 Max. vertical digging depth (long stick) 1850 mm (73 in) 1760 mm (69 in)
F1 Max. digging height (short stick) 3840 mm (12'-7'') 3930 mm (12'-11'')
F2 Max. digging height (long stick) 3960 mm (13'-0'') 4050 mm (13'-3'')
G1 Max. tilt-out height (short stick) 2720 mm (8'-11'') 2810 mm (9'-3'')
G2 Max. tilt-out height (long stick) 2840 mm (9'-4'') 2930 mm (9'-7'')
H1 Max. reach at ground level (short stick) 4030 mm (13'-3'') 4000 mm (13'-1'')
H2 Max. reach at ground level (long stick) 4230 mm (13'-11'') 4200 mm (13'-9'')
K1 Max. digging radius (short stick) 4130 mm (13'-7'')
K2 Max. digging radius (long stick) 4330 mm (14'-2'')
M Max. boom displacement to bucket center (right side) 520 mm (20 in)
N Max. boom displacement to bucket center (left side) 360 mm (14 in)
O Max. lift height of stabilizer blade over ground (short) 220 mm (9 in) 270 mm (11 in)
O Max. lift height of stabilizer blade over ground (long) 300 mm (12 in) 360 mm (14 in)
P Max. scraping depth of stabilizer blade below ground surface (short) 300 mm (12 in) 260 mm (10 in)
P Max. scraping depth of stabilizer blade below ground surface (long) 360 mm (14 in) 320 mm (13 in)
R1 Min. tail end swiveling radius 1160 mm (46 in)
R2 Boom swivel radius (center) 1660 mm (65 in)
R3 Boom swivel radius (right) 1580 mm (62 in)
R4 Boom swivel radius (left) limit 1450 mm (57 in)
R5 Max. boom swivel radius (left) 1350 mm (53 in)
S Total running gear length 1710 mm (67 in)
T Running gear length (Turas front idler) 1325 mm (52 in)
V VDS tilt angle - 0 – 15°
W1 Max. tilting angle of boom to the right 48°
W2 Max. tilting angle of boom to the limit on the left 64°
W3 Max. tilting angle of boom to the left 77°
X Track width 250 mm (10 in)
Y1 Stabilizer blade width 990 mm (39 in)
Y2 Stabilizer blade width with extension (only telescopic travel gear) 1300 mm (51 in)
Z Stabilizer blade height 230 mm (9 in)
