7-38 BA E14 track en* 1.3 * E14t_13_700.fm
7 Maintenance
Empty water separator (main filter) (ET65/EZ80)
Empty the water separator if the error message SPN 97 appears on the
multi-functional display.
1. Stop and park the vehicle. Stop the engine. See āPreparing
lubricationā.
2. Prepare a suitable container for collecting the fuel/water mixture.
3. Open the valve cover.
4. Connect a suitable hose to the drain device A.
5. Open drain valve B.
6. Loosen bleed screw C.
7. Drain the fuel/water mixture into a receptacle (1).
8. Tighten bleed screw C.
9. Close drain valve B if nothing but fuel is visible in the sight glass (2).
10.Remove the hose.
11.Close and lock the valve cover.
Use a suitable container to collect fluids and lubricants as they flow out
and dispose of them in an environmentally friendly manner.
Fig. 292 (symbolic representation)
C
B
A
Fig. 293 (symbolic representation)
B
2
1
