Technical data
BA RD24_RD28 en us 06
133
5.01 Technical data
NOTE
The version valid at the time the technical data was prepared for this version of the manual was
used (see impressum: change date). Other values may apply if modifications are made to the
machine in the course of its further development.
000-30
5.01.01 RD 24-100
Designation Value Unit
Dimensions and weights
Unladen weight without ROPS roll-over bar 2234 kg
Operating weight with ROPS roll-over bar 2475 kg
Axle load front / rear 1205 / 1270 kg
Working width / max. working width 1000 / 1050 mm
Turning radius inside / outside 2470 / 3470 mm
Diesel engine
Manufacturer Kubota
Type D1703
Number of cylinders 3
Power (ISO 14396) / rated speed 22.9 / 2700 kW / rpm
Emission level EU / USA V/Tier 4
Carbon dioxide emissions (CO
2
)
(1)
938.3 g/kWh
Transmission
Working gear speed 0 - 12 / (0 - 7.5) km/h / (mph)
Climbing ability, vibration on / off 30 / 40 %
Max. longitudinal gradient allowed 20 °
Max. transverse gradient allowed 20 °
Vibration
Vibration front / back
Frequency / speed, engine speed max. 67 / 4020 Hz / rpm
Frequency / speed, engine speed 2/3 max. 52 /3120 Hz / rpm
Maximum amplitude 0.45 mm
Steering
Steering angle to both sides 32 °
Pendulum compensation upwards and downwards 8 °
Track offset
Track offset to the right 50 mm
