Wacker Neuson RD 24 User Manual

Tables
Technical data
BA RD24_RD28 en us 06
143
5.01.06 RD 28-120 C
Designation Value Unit
Dimensions and weights
Unladen weight without ROPS roll-over bar 2344 kg
Operating weight with ROPS roll-over bar 2595 kg
Axle load front / rear 1340 / 1255 kg
Wheel load per tyre 313.75 kg
Working width / max. working width 1200 / 1220 mm
Turning radius inside / outside 2370 / 3570 mm
Diesel engine
Manufacturer Kubota
Type D1703
Number of cylinders 3
Power (ISO 14396) / rated speed 22.9 / 2700 kW / rpm
Emission level EU / USA V/Tier 4
Carbon dioxide emissions (CO
2
)
(1)
938.3 g/kWh
Transmission
Working gear speed 0 - 12 / (0 - 7.5) km/h / (mph)
Climbing ability, vibration on / off 30 / 40 %
Max. longitudinal gradient allowed 20 °
Max. transverse gradient allowed 20 °
Tyres
Tyre size 9.5/65-15
Number of tyres rear 4 items
Weight of tyres 45 kg
Air pressure 0.3 / (3.0) / [44] MPa / (bar) / [psi]
Tightening torque, wheel nut 170 Nm
Vibration
Vibration front
Frequency / speed, engine speed max. 67 / 4020 Hz / rpm
Frequency / speed, engine speed 2/3 max. 52 / 3120 Hz / rpm
Maximum amplitude 0.45 mm
Steering
Steering angle to both sides 32 °
Pendulum compensation upwards and downwards 8 °
Track offset
Track offset to the right 50 mm
